BC-832 Bincolor Led Controller 12V-24V PWM CV DMX512/1990 Decoder 2CH

$31.21
In stock
SKU
BC-832 Bincolor Led Controller 12V-24V PWM CV DMX512/1990

BC-832 Bincolor Led Controller 12V-24V PWM CV DMX512/1990 Decoder 2CH is high quailty LED product for lighting decoration projects, For big order or customized order, Pls feel free to contact service@vozop.com

Vozop.com supply advanced, durable and effective LED products to USA, UK, Germany, France, Spain and other counties for many years.  Quality LED lighting equipment and systems with the latest technology.Quick shipping with tracking number, easy and safe ordering with PayPal.

Feature function:

Automatically adapt input voltage DC12V-24V.

Input standard DMX512 signal; 3-digital-display shows DMX address code..

2(BC-832)/3(BC-833)/4(BC-834) channels output; 4096 grey scales each;

logarithmic dimming; lamplight soft& stable without strobe flash.

DMX Master mode, Slave mode available.

4 (BC-832)/8 (BC-833)/8 (BC-834)color changing modes and 10 speed scales in master mode .

Indicator of the DMX512 signal receiving status.

Wrong wiring protection at DMX input port.Over current protection and short circuit protection.

Power loss memory function.

BC-832

Product Model:BC-832

Input voltage:DC12V-DC24V

Max load current:8A/CH×2

Max Output Power:192W(12V)/384W(24V)

Grey Scale:4096 levels×2

Input Signal:DMX512/1990

Output Signal:Constant Voltage PWMX2

Decode Channel:2CH

DMX512 socket:Terminal Block

Dimension:L176×W46×H30(mm)

Weight (G.W):170g

Package Content:

1 Piece of BC-832 Bincolor Led Controller 12V-24V PWM CV DMX512/1990 Decoder 2CH

1 Piece of User's manual

Bincolor_Controller_BC_832_1
Bincolor_Controller_BC_832_2
Bincolor_Controller_BC_832_3
Bincolor_Controller_BC_832_4
Bincolor_Controller_BC_832_5
Bincolor_Controller_BC_832_6
Bincolor_Controller_BC_832_7
Bincolor_Controller_BC_832_8

CE and RoHS approved
